- RAL 9002 : off White Description Galvanized Temporary fence (Panel Type) for construction sites as per DM approved. Economical for pocket. Available in all colors Material Specifications (Regular) GI (PANEL TYPE) FENCE FOR PROJECT:- Fabrication & supply of GI Fencing includes RCC Blocks ■ Fence will be .32mm corrugated profile sheet- 35/200 ■ Pipe will be 42 mm OD G.I- 1.1mm (T) ■ U Channel- 40x40x40mm- 1.1mm (T) ■ Fence color off white- (RAL 9002) [Optional : PCC Blocks – 600x400x200 mm each every 2.18 mtr CC.w/o Hook] ■ Clamp- G.I Standard clamp ■ Support Pipe (L)- 170cm ■ Fence (H) 2mtr.x 2.18(W)- clamp to clamp ■ Fence height from ground level 2.2mtr incl bocks Customize your product:
- 60 x 40 x 20 CM x 115 KG
- Printing of High-Resolution PVC Banner with High Quality Ink Digital Print with Top and Bottom fixing by Rivet on hoarding.
- Aluminum fence with Customer Supplied design - [Price varies as per the design]
- Steel Structure Signage : as per approved design from Client: Signage Aluminum Sign with Sticker - Include Signage +Back Support + Base Plate + Anchor Bolt +Paint + Pipe Frame and all necessary materials with epoxy paint finish. - Sign board containing Project Perspective, Building Permit No., Plot No., Project Name, Client Name, Consultant, Contractor, Sub-Contractor Name (or as per approved design) - Size: As per Approved Design - Include Delivery (Exclude Crane / Exclude Foundation)
- Car Parking Shade: - Fabrication and supply of car parking shade with steel structure and foundation. Description -PVC fabric (Color Beige). - Size of shed: 2.7 x 5.0mtr (for each car) Height:2.40mtr from ground level [Standard] - PVC fabric- steel section + epoxy coating + Base plate + Column + Arc members + Pipe + anchor bolts + Horizontal members - Exclude Foundation
- NC Paint Finish Colors
- NC Paint Finish Colors
- RAL Paint FInish Colors
- RAL 6005 Description Beautiful and strong fence. Mainly use for playgrounds, parks, Farms, Buildings, High-security areas and sites. Material Specifications.(Regular) WELDED MESH FENCE FOR PROJECT:- ■ Fabrication & supply of Welded Mesh Fence ■ Size: 2200mm(W) X 2000mm(H) ■ Hole size :50 X 200mm ■ Wire Dia.: 4mm ( After coated) ■ Post: 50 X 50 X 2mm(T) X 2500mm(H), with underground 500mm ■ Surface : Galvanized + Green powder coated [Optional: Foundation: 60x30x 30cm x 2.2mtr CC] ■ Exclude excavation for foundation.
- RAL 7035
- RAL Colors :White Description Eco-Friendly and strong fence. Beautiful in look, perfect for branding. Specially made for high profile projects keeping in view of UAE weather. Material Specifications. (Regular) PVC - ECO HOARDING FOR PROJECT:- ■ Fabrication and supply of PVC –Eco hoarding ■ Off-white flat Panel hoarding 2.4mtr (h) ■ Pipe height 2.2 mtr. [Additional : Foundation size: 1000 x 600 x 600mm at 2.5mtr cc]
- RAL 9006 Description Moveable fence easy to install and remove, Good for event organization and expo’s to control the crowd. Also helpful to do branding. Material Specifications.(Regular) HERAS FENCE FOR PROJECT:- ■ Fabrication & supply of Heras Fence. ■ Surface: Hot Dip Galvanized + Silver ■ Fence Color RAL 9006 ■ Mesh opening :100 X 50mm ■ Wire Di.: Horizontal :4mm, Vertical: 3mm ■ Frame Pipe: Horizontal : 32X1mm(T) ■ Back support 2m x 42 OD x 1.1mm ■ Clamp Standard 3mm [Optional : PCC Foundation 600 x 200 x 200mm x 3.5mtr CC] ■ Size: 3500mm(W) X 2000mm(H) ■ (From ground fence height is 2.20mtr including blocks)
- Any RAL Color
- RAL 6005 Description Beautiful and strong fence. Mainly use for playgrounds, parks, Deserts, Farms, Buildings, High-security areas and sites. Material Specifications. (Regular) PVC - CHAIN LINK FENCE FOR PROJECT:- PVC CHAINLINK FENCING 2.2/3.2mm x 50X50mm fence color RAL 6005 ■ Fence height 2 mtr ■ LINE WIRE – 3.55/4mm Dia 5 rows- Top row with double wire ■ STIRRUP WIRE - 2.50/3.55 mm DIA. ■ TIE WIRE- 1.40/2.00 mm DIA ■ INTERMEDIATE POST 60mm OD (2mm THK) MS PIPE @ EVERY 3 MT C/C ■ STRAINING POST 76mm OD (2mm THK) MS PIPE WITH 2 NOS. @ EVERY 45 MT C/C ■ CORNER POST 76mm OD (2mm THK) MS PIPE @ EVERY CORNER ■ END POST 76mm OD (2mm THK) MS PIPE ■ All posts NC paint finish Green color RAL 6005. [Optional: Foundation size 60 x 30 x 30 x3mtr cc exclude excavation for foundation]
- RAL 9002 Description Galvanized Temporary fence (Continuous Type) for construction sites as per DM approved. Available in all colors (Good for branding also). Material Specifications.(Regular) CONTINUOUS GI FENCE FOR PROJECT: Fabrication & supply of CONTINUOUS GI FENCE includes RCC Blocks ■ Fence will be .40mm corrugated profile sheet. 9002 color ■ Pipe will be 48 mm OD G.I- 2mm (T) front and back ■ U Channel- 40x40x40mm- 1.2mm (T) ■ Fence color off white- (Ral 9002) ■ RCC Blocks – 600x400x300 mm each every 2.44 mtr CC. ■ Clamp & Coupler - G.I Standard. ■ back Support Pipe (L)- 2 mtr & 1.20 mtr - ■ Fence 2 meter Height & from ground 2.30 mtr incl bocks
- RAL 6005 Description Anti Climb/High Security fence specially for high security or public prohibited entrance areas like Borders, Plants. Government high security projects etc. Material Specifications.(Regular) Anti-Climb Fence:- Fabrication and supply of Anti Climb Fence Mesh Include Foundation. ■ Mesh size 76.2 × 12.7mm × 4.0mm Dia after powder coating Mesh. ■ Fence panel size: 2150mm (w) × 2500mm (h) panel height. ■ Post 2500, 60 x 2.5mm (T) ■ Surface: Galvanized+ powder coating (RAL 6005 Green or RAL 9005 Black). ■ 5 clips (Thickness 2.6mm) ■ Bolts 8mm ■ 1 welded floor plate thickness 8.0mm ■ Foundation: 60x40x40cm Customize your product:
ALTON GROUP - Fencing Suppliers in Dubai
ALTON group is one of the most respected, well known Fencing, Steel fabrication, Pre-cast blocks, Fence branding, Construction signage and Advertising company in United Arab Emirates since our journey started in 1998; ISO certified and with branches in Dubai and Sharjah.
Our production division is having wide variety of machinery, tools, designing section & skilled workers to handle projects delivering high quality standards, on-time and competitive price. We have undertaken turnkey projects of various prestigious clients in UAE, other GCC, US, Bangladesh and South Africa.
