CHAIN LINK MESH GATE

NC Paint Finish Colors

RAL 9002 : off White

Description

Galvanized Temporary fence (Panel Type) for construction sites as per DM approved. Economical for pocket.

Available in all colors

Material Specifications (Regular)

GI (PANEL TYPE) FENCE FOR PROJECT:-

Fabrication & supply of GI Fencing includes RCC Blocks

■ Fence will be .32mm corrugated profile sheet- 35/200
■ Pipe will be 42 mm OD G.I- 1.1mm (T)
■ U Channel- 40x40x40mm- 1.1mm (T)
■ Fence color off white- (RAL 9002)
[Optional : PCC Blocks – 600x400x200 mm each every 2.18 mtr CC.w/o Hook]
■ Clamp- G.I Standard clamp
■ Support Pipe (L)- 170cm
■ Fence (H) 2mtr.x 2.18(W)- clamp to clamp
■ Fence height from ground level 2.2mtr incl bocks

Customize your product:
